product Image
Thermo-Electric Actuator Ø18
Model Name
-
Data
Catalog-Vernet Group-Actuator-Thermo-Electric Actuator Ø18
Manufacturer information
provider logo
Vernet Group

Actuator, Thermostatic Cartridge, Safety Cartridges, Dense Phase Pump and more

Problem with product info?
Update request
Manufacturer
Vernet Group
Brand
-
SKU
140095
Product Name
Thermo-Electric Actuator Ø18
Model Name
-
Size
-
Weight
-
Product Details

Technology & Features

The Vernet Thermo-Electric Actuator is a thermostatic wax element which transforms electrical energy into force and movement.

  • Energy is supplied by a 24, 110, or 240 Volts PTC heater. (Positive temperature coefficient resistor).
  • Movement is obtained by wax volume expansion and contraction when power is either ON or OFF.
  • This movement is used for remote control of valves, sliders, shutters, ventilation, etc...





Main Advantages

  • Compact size
  • Silent movement
  • Powerful force
  • Linear movement
  • Long life
  • Low cost





Technical Data

Operating Voltage 24, 110, 240 Volts
Ambient operating temperature up to 60° /140°F
Stroke 4mm/0,156”
Minimum load 45N
Maximum load 140N
Response time Start to move between 60 to 180 seconds 2/3 of nominal stroke between 120 to 360
seconds





Operating Curve





Dimensions (in mm)
