Heating, Cooling, Temperature indicator, Digital temperature controlling device and more
Housing | ABS incombustibility grade V0 |
Dimension | H80xL40xD77mm |
Input Sensor | Pt-100Ω probe |
Resolution | 1℃ |
Power Supplay | Trans external |
12V AC/DC , 24V DC | |
Temp Range | -50 ~ 500℃ |
Output | On/Off relay 10A 250V AC |
Alarm relay 10A 250V AC | |
Uses | Possible to use at high temperature, like an oven and a frier, and a control panel |
Upper and lower limit alarming |
