Heating, Cooling, Temperature indicator, Digital temperature controlling device and more
Housing |
ABS incombustibility grade V0 |
Dimension | H80xL38xD65mm |
Input Sensor | NTC 5KΩ、25℃ |
Resolution | 0.1℃ |
Power Supplay | 220V 50/60Hz (order production: 110V, 240V 50/60Hz, 12or24V AC/DC) |
Temp Range | -20.0 ~ 99.9℃ |
Output | On/Off relay 5A 250V AC |
Alarm relay 5A 250V AC | |
Uses |
Upper and lower limit alarmin |
Used for the control of cooling and heating temperature |
