Specification
Valve Size | 15A ~ 150A | ||
Actuator Model | AD50 ~ AD100 | ||
Actuator Type | Double Acting | ||
Operating Media | Compressed Dry Air | ||
Operating Pressure | 4 ~ 7kg/㎠ | ||
Rotating Angle | 90 ˚ ±3 ˚ | ||
Fluid Temperature | -10 ~ 90℃ (-40 ~ 140℃) | ||
Rating |
JIS 10K |
ANSI 150# | |
Body Material | PVC, PP, PPG, C-PVC, PVDF | ||
Accessory | Solenoid Valve, Air filter Regulator, Limit Switch Box, E-P Positioner |
※ (Option)
