Application
■ Water distribution pipes
■ Industrial cleaning machines
■ Dyeing machine temperature control
■ Middle and low stem equipments control
■ Well water and wastewater disposal plant
Specification
Valve Size | 15A ~ 50A |
Actuator Type | Cylinder type |
Actuator Action | Single acting (air to open, spring close) |
Operating Media | Compressed dry air |
Operating Press | 4 ~ 7kg/㎠ |
Liner Adjust | None manual handle |
Fluid Temp | -30 ~ 160℃ |
Connection | Screw, Welding |
Body Material | SUS304 |
Leakage allowance | ANSI Class V (0.005%) |
Accessory | Solenoid Valve, Air filter Regulator |
※ (Option)
