회로용 Dry Film 공정에서 노광후 보호용 Mylar Film을 수평으로 Peeling 하는 설비
Standard Type
초박판 대응이 원활한 장비이며, 평판 테이블에 기판을 Pick up 하고 테이프를 점착하여 1면씩 박리하여 배출
Compact Type
박판 제품 Handling 대응에 적합한 장비이며, 장비 Size 최소화로 공간 제약이 있고 Tact Time이 빠르지 않는 Package 기판에 제안.
Specification
Items | Standard Type | Compact Type |
Work Size | 510mm × 610mm / 405mm × 510mm | 405(~415)mm × 510mm |
Work Thickness | 0.04mm ~ 1.2mm | 0.04mm ~ 1.2mm |
Tact Time | 13sec (Customize) | 16sec (Customize) |
Footprint | Main MC : 2,350(L) × 1,250(W) × 1,850(H) Box Loader (additional) : 1,400(L) × 1,250(W) × 1,850(H) | Main MC : 1,850(L) × 1,250(W) × 1,850(H) Box Loader (additional) : 1,400(L) × 1,250(W) × 1,850(H) |
Structure | Main Auto Peeler MC In Line or Loading System | Main Auto Peeler MC In Line or Loading System |
Loading Unloading (Customize & Option) | In Line to DES or N.C Developing MC Loading MC to DES or N.C Developing MC | In Line to DES or N.C Developing MC Loading MC to DES or N.C Developing MC |
Applications. | Package Substrate, HDI DF Process | Package Substrate, HDI DF Process |
※It is subject to change without any notice for better quality, and a customizable equipment.
