Range of modular band harvesting belts (drive by pinions), adapted to the needs of the harvester.
RANGE
TYPES | TDSH 70 | TDTH 80 | TDTH 90 | TDTH 110 | TDTH 120 |
---|---|---|---|---|---|
Useful length | 7.50 m | 8.00 m | 9.00 m | 11.00 m | 12.00 m |
Number of aluminum boxes | 2 + extension sliding |
2 + extension sliding |
3 | 4 + extension sliding |
4 + extension sliding |
Number of aluminum boxes hydraulic unfolding |
1 | 2 | 2 | 2 | 2 |
Number of aluminum boxes manual unfolding (excluding extension) |
1 | 0 | 1 | 2 | 2 |
STANDARD EQUIPMENT
Frame and first steel box |
Aluminum monohull housings |
Sliding carriage for adjusting the working height |
Cap 0.75 m (interior trailer reception area) |
Modular polypropylene band 400 mm wide; reinforced edge modules |
Cleats 75 mm high, at 380 mm intervals |
Driven by 4 double-tooth pinions |
Hydraulic motorization with variable speed drive on distributor |
Conveyor stop by photoelectric detector |
Choice of: conveyor outlet side and position of controls (front / rear) |
OPTIONS
Wrapping table 3 or 4 boxes (with or without rollers), parallel or perpendicular to the belt |
Hydraulic displacement in the trailer: external rollers in rail or on the edge of the platform |
Pass-through frame for passage over pallets |
Cap 1.00 m |
TDTH 90: sliding extension for useful length 10.00 m |
No custom cleats |
Hydro-electric reel: passage through central rail or roof |
Kit for crating along the belt |
Salad sprinkler kit (aluminum tank under the floor of the trailer) |
Step |
Pivot for right or left outlet |
Epoxy paint (primer) |
TDSH70: 2nd hydraulic box |
TDTH90 / 110/120: 3rd hydraulic box |
Platform mounted on a 3-point system (with hitch for platform) |
