Hose Size | Hose I.D. | Hose O.D. | Working Pressure | Burst Pressure | MIN.Bend Radius | Weight | |||||
mm | Inch | mm | Inch | bar | psi | bar | psi | mm | Inch | kg/m | |
3/8″ | 9.5 | 0.38 | 21.4 | 0.84 | 445 | 6453 | 1780 | 25812 | 130 | 5.1 | 0.80 |
1/2″ | 12.7 | 0.50 | 24.6 | 0.97 | 415 | 6018 | 1660 | 24072 | 180 | 7.1 | 1.15 |
3/4″ | 19.0 | 0.75 | 32.2 | 1.27 | 350 | 5075 | 1400 | 20300 | 280 | 11.0 | 1.44 |
1″ | 25.4 | 1.00 | 39.7 | 1.56 | 280 | 4060 | 1120 | 16240 | 355 | 14.0 | 2.15 |
1-1/4″ | 32.0 | 1.25 | 50.8 | 2.00 | 210 | 3045 | 840 | 12180 | 460 | 18.1 | 2.75 |
1-1/2″ | 38.0 | 1.50 | 57.2 | 2.25 | 185 | 2683 | 740 | 10732 | 560 | 22.0 | 3.35 |
2″ | 50.8 | 2.00 | 69.8 | 2.75 | 165 | 2393 | 660 | 9572 | 710 | 28.0 | 4.60 |
