Fig no.
HSC-I
Pressure rating
? / ? lbs
Size range
3/4 - 3
Features
Design: Straight, Angle
Service: Cavitating condition up to 600 LBS
Leakage class: IV, V
Cv range: 2.5 - 23
Flow characteristic: Unique
Rangeability: 200:1 (Maximum)
