Rated Voltage(V)
|
AC 220/110, DC 24
|
|||
Frepuency(Hz)
|
50/60
|
|||
Size of Orifice(mm)
|
4, 5
|
|||
Spec
of Tube |
O.D
|
IN
|
3/8-18UNF
|
|
OUT
|
3/8-18UNF
|
|||
Connection
|
All-in-one Body
|
|||
Working
Pressure Differential Range |
Max. Kg/㎠(Mpa)
|
0
|
||
Min. Kg/㎠(Mpa)
|
21
|
|||
Max Working Pressure Kg/㎠(Mpa)
|
40(4)
|
|||
Deenergized Porsition
|
Close
|
|||
Max. Flow Range cc/Min
|
3,600 and over
|
