포장기 모델 | FW3400/FW3700 | FW3410/FW3710 | ||
---|---|---|---|---|
엔드실 지름 | RD81 | RD114 | RD114 | RD150 |
포장 속도 | 10 to 300 pieces/min | 10 to 300 pieces/min |
10 to 500 pieces/min |
|
포장 길이 | 60 to 250mm | 80 to 250mm | 100 to 250mm | 120 to 450mm |
Up to 3,999mm according to the spec |
Up to 3,999mm according to the spec |
|||
포장가능 제품 사이즈 |
Width:UP to 140mm | Width:UP to 200mm | ||
Height: Up to 430mm |
Height: Up to 60mm |
Height: Up to 60mm |
Height: Up to 100mm |
|
포장필름 | Width:UP to 430mm | Width:UP to 600mm | ||
Outside diameter:Up to 300mm | Outside diameter:Up to 300mm | |||
구동용량 | 200V 1.835kw | 200V 1.835kw | ||
히터용량 | 1.42kw | 1.82kw | 2.32kw | |
사이즈 | 4,140(L)X1.095(W)X1,470(H) | 4,140(L)X1.145(W)X1,470(H) | ||
중량 | About 850kg | About 950kg |
