Features
- Size : 3.4 x 3.2 x 1.8 (0.6) mm
- Eliminates the need for an external optics
- Wide beam angle for uniform illuminance
- Super slim and high CRI
Applications
- Mobile, Tablet PC Flash
Specifiations
Model | Size [mm] |
Forward Current [mA] |
Luminous Intensity [cd] |
Luminous Flux [lm] |
Forward Min Voltage [V] |
Chip | CCT [K] |
Viewing Angle [deg.] |
3432 | 3.4 x 3.2 x 1.8 | 1,000 | 180 | 300 | 3.1 | 2 | 5,600 | 80˚ |
3.4 x 3.2 x 0.6 | 1,000 | 110 | 260 | 3.1 | 2 | 5,700 | 120˚ |
