적용: 건물설비, 대단위 공장, 화학, 철강 산업 등 산업 전반
소형, 경량 (Light weight and Small size)
광범위한 선택성 (Wide variety selection)
낮은 서지 (Low Surge)
응용성 (Applications)
Standard specification | Order specification | ||||
Item | Quantity | 기호 | |||
Control Source | Nonlatched | AC 100/110 (PT secondary) | - | - | 200/220V> (PT Control source) |
Latched | AC 100/110 (shunt trip) | - | L | C.TD AC 100/110V 200/220V (PT Control source) | |
Draw-out mechanism Interlock | 1set | LS3 | Limit s/w (LS3) Addition | ||
Front Shutter (Handle drawable type) | 1set | F2 | Manul drawable type | ||
Front Cover (Manual drawable type) | 1set | Handle drawable type | |||
Shutter padlock | - | - | - | ||
Position padlock | - | - | - | ||
Earthing s/w | - | - | Earthing s/w installatoin | ||
Power fuse | 3phase | - | PT delete (short-circuit conduct addition) | ||
LS4 | Micro s/w addition(fuse checker) | ||||
P.T(Nonlatch type) | 1pc | - | PT addition | ||
- | PT delete | ||||
- | PT addition (Latch type) | ||||
Counter | 1SET | C2 | Counter installation | ||
Connection plug for control circuit (1.2㎣ wire) | 1set | - | Other size available by request |
