NAME |
TYPE |
P2 (KW) 50HZ / 60HZ |
DUAL-FREQUENCY (50/60HZ) |
Q MAX 50HZ |
H MAX 50HZ |
DN |
CX 54 |
3 ph |
0.65 / 1.0 |
O.D. |
55 |
55 |
1/2G |
CXm 54 |
1 ph |
0.65 / 1.0 |
O.D. |
55 |
55 |
1/2G |
CHARACTERISTICS
- Continuous duty S1.
- 2 pole motor.
- Insulation class F.
- Protection IP42 (IP 54 on demand).
- IE3 efficiency class for 3-phase motors >0,75 kW.
- Working tolerance: +/- 10%.
- Liquid temperature (with anti-freeze additive): -20 °C / +90 °C.
- Limit ambient temperature : +40 °C.
- Normal priming, manometer suction up to 5m.
- For clear waters/oils and non-aggressive dilutions, without abrasive substances.
Hydraulic characteristics for water 20°C at nominal pump speed. Tolerance according ISO 9906-2012
ON REQUEST
- Special voltages.
- 60Hz version.
- Dual-frequency.
- Special fluids with temperature <180°C.
- UL/CSA.
MATERIALS
- Casing AISI316
- Impeller PEEK
- Shaft AISI316
WEIGHT
8 Kg
IN ACCORDANCE WITH
- EN 60034-1
- EN 60034-30
- EN 60335-1
- EN 60335-2-41
DIMENSIONS
![](https://cdn.komachine.com/media/product-desc/7cfcbe3e-e0e3-44c0-8d84-c9b7b384d3b6)
HYDRAULIC PERFORMANCE
![](https://cdn.komachine.com/media/product-desc/be364970-1b08-427f-8c43-69b621a5c0c5)
