OPTICAL
CPU : 32 Bit
Light Source : Visible Laser Diode 670nm ± 10nm
Scan rate : 58 Scans per Second
Skew Angle : ±65 Degree
Pitch Angle : ±50 Degree
Resolution : 4mil (0.1mm)
Field Width : 120mm (25mil)
Depth of field : 30~350mm (15.6mil)
Symbologies : UPC/EAN/JAN, Code39, Interleaved 2 of 5 Standard 2 of 5, Matrix 2 of 5,
                     Industrial 2 of 5, Codabar, Code128, MSI, Plessey, Code93, Code 3 of 5 (Korean Postage)
Interface : USB, IBM PC XT/AT/PS2 Keyboard wedge, Standard RS-232C, TTL serial, Wand emulation

MECHANICAL
Dimensions : 95mm*20mm*160mm
Weight : 150g
Cable : 2m Straight Fixed to Scanner
Body Material : ABS Plastic

ELECTRICAL
Power Supply : 5VDC ± 10%
Current Active : K/W : 70mA ~ 130mA / USB : 80mA ~ 135mA / RS-232 : 75mA ~ 110mA
DURABILITY
Trigger Switch : 1 million Actuations
Cable : 100,000 Bending at 90 degree with 500g weight
Shock Resistance : 1 meter drop onto Concrete Surface

ENVIRONMENTAL
Temperature : Operating : 0 ~ 50°C, Storage : -20 ~ 65°C
Humidity : Operating : 10% ~ 80%, Storage : 0% ~ 95%
Ambient Light : 3,000 to 8,000 lux
Mechanical Shock : Functional after 1.5m (5ft) drops
ESD Protection : Functional after 15kV discharge
