PERFORMANCE
CPU : 32Bit
Scanrate : 125 Scans per Second
Resolution : 4mil (0.1mm)
Photo Sensor : 2048 Pixel Linear CCD
Illumination : 660nm Visible Red LEDS
Skew Angle : ±65 Degree
Pitch Angle : ±50 Degree
Field Width : 100mm (15mil)
Depth of field : 0~150mm
Symbologies : UPC/EAN/JAN, Code39, Interleaved 2 of 5 Standard 2 of 5, Matrix 2 of 5,
Industrial 2 of 5, Codabar, Code128, MSI, Plessey, Code93, Code 3 of 5 (Korean Postage)
Interface : USB
Data storage Memory : 32 Kbyte (ex. UPC/EAN 2300 events)
Radio Range : 30M open air
MECHANICAL
Dimensions : 75mm X 51mm X 170mm
Weight : 144g
Body Material : ABS Plastic
ELECTRICAL
Power Supply : (3.7 Voltage) Li-Pol 560mA
Power Consumption : Normal 10mA Max 150mA(CCD)
Battery Life : Up to 10,000 Scans
DURABILITY
Trigger Switch : 1 million Actuations
Shock Resistance : 1 meter drop onto Concrete Surface
ENVIRONMENTAL
Temperature : Operating : 0 ~ 50°C, Storage : -10 ~ 60°C
Humidity : Operating : 10% ~ 80%, Storage : 10% ~ 95%
Mechanical Shock : Functional after 1.5m (5ft) drops
ESD Protection : Functional after 15kV discharge
