TECHNICAL DESCRIPTION
ㆍPOWER SOURCE: 220V x 1
ㆍPRESSURE RANGE : 0.5~4 kgf/
ㆍRUBBER THICKNESS : 0.84~0.89
ㆍOIL PRESSURE SPEED : 95 10/ min
ㆍMOTOR : 220V, 1, 90W
ㆍPRESSURE GUAGE : 60 kgf/ or 10 kgf/
ㆍAIR PRESSURE : 4 kgf/
ㆍPAPER HOLDING TYPE : AIR CYLINDER
ㆍDIAPHRAGM : FOR PAPER(IMPORTED)
ㆍBODY MATERIAL : STEEL PLATE(PAINTING)
ㆍSIZE : 330 x 700 x 640(W*D*H)
