기본사양
Travel Angle : 20˚
Voltage : 24V
Inductance(φ:0˚) : 13mH
DC resistance(@20˚C) : 20Ω
■ SPECIFICATION
Travel angle | 20˚ |
---|---|
Voltage | 24V(duty rate 20% or less) |
DC resistance(@20˚C) | 20Ω |
Inductance(φ=0˚) | 13mH |
Time constant of temperature rise |
5 minutes |
Heat resistance class | Class F (155˚C) |
Insulation resistance | DC 500V MEGA, Over 100MΩ |
Dielectric strength | AC 500V, 50/60Hz, 1minute |
Rotor inertia | 10g-cm² |
Mass | 60g |
Starting torque (24VDC) |
20mN-m |
Non-energized holding torque |
15mN-m |
Response characteristics (No-load,horizontally placed) |
6ms at 24V |
