기본사양
Travel Angle : 90˚
Voltage : 8.3VDC
Inductance(φ:0˚) : 4.5mH
DC resistance(@20˚C) : 15.6Ω
■ SPECIFICATION
Travel angle | Up to 90˚ |
---|---|
Voltage | 8.3 VDC |
DC resistance(@20˚C) | 15.6Ω |
Inductance(φ=0˚) | 4.5mH |
Time constant of temperature rise |
7 minutes |
Heat resistance class | Class E (120˚C) |
Insulation resistance | DC 500V MEGA, Over 100MΩ |
Dielectric strength | AC 1000V, 50/60Hz, 1minute |
Rotor inertia | 1.8g-cm² |
Mass | 65g |
