Travel Angle : 90˚
Voltage : 15.0VDC
Inductance(φ:0˚) : 140mH
DC resistance(@20˚C) : 32Ω
■ SPECIFICATION
Travel angle | Up to 90˚ |
---|---|
Voltage | 15.0 VDC |
DC resistance(@20˚C) | 32Ω |
Inductance(φ=0˚) | 140mH |
Time constant of temperature rise |
5 minutes |
Heat resistance class | Class E (180˚C) |
Insulation resistance | DC 500V MEGA, Over 100MΩ |
Dielectric strength | AC 1000V, 50/60Hz, 1minute |
Rotor inertia | 2.1g-cm² |
Mass | 80g |
■ Dimensions
■ Torque characteristics
■ Response characteristics(no-load)
