Torque Table (N-m)
Model | Angle | 4.5bar | 5bar | 6bar | Spring | Model | Angle | 4bar | 5bar | 6bar | Spring | |
AS200 | 0 ˚ 45 ˚ 90 ˚ |
680 425 510 |
805 542 630 |
1050 705 820 |
720 936 1080 |
AS200D | 0 ˚ 45 ˚ 90 ˚ |
1360 850 1020 |
1610 1085 1260 |
2100 1365 1610 |
1320 1716 1980 |
Torque Curve
