Special Feature
* High-speed cutting of medium or thick plates
* Concentrated cutting heat minimizes thermal deformation
* Novices may also work because of the durability and simple operation
* Built-in self-inspection function of the disorder of the machine
* 220V/380V/440V combined use
Specification |
||
Output Current |
A |
3 Phase - 130 |
1 Phase - 90 |
||
Input Voltage |
V |
220V ± 10% |
Rated Frequency |
Hz |
50/60 |
Rated Input |
KVA |
19.8 |
Rated load Voltage |
V |
140 |
Output Current range |
A |
25-130 |
Duty Cycle |
% |
50 |
Dimension (WxDxH) |
W*D*H (m/m) |
360 x 623 x 580(360 x 693 x 615) |
Weight |
kg |
52 |
※ Product specifications can be changed unexpectedly for product performance improvement.
