Hydraulic Press KDP-100,KDP-150A,KDP-150B,KDP-200A,KDP-200B by KMC PRESS - Komachine Supplier Profile and Product List

This product is manufactured by

KMC PRESS

Home

Manufacturers

KMC PRESS

Hydraulic Press

TOP

Hydraulic Press

Model Name

KDP-100

Series

Hydraulic Press

View AllView All Series

Data

Manufacturer information

KMC PRESS

Press machinery manufacturer, Mechanical press, Hydraulic press and more

Inquiry

How to order

Problem with product info?

Update request

Manufacturer

KMC PRESS

Brand

SKU

16310

Product Name

Hydraulic Press

Model Name

KDP-100, KDP-150A, KDP-150B, KDP-200A, KDP-200B, KDP-250B, KDP-300B, KDP-400B, KDP-500B, KDP-600, KDP-800, KDP-1000

Size

Weight

Product Details

It is to have a compacted structure due to Valve Block integrate all functions on complicated circuits, and to be made solidly, so it is profitable to service and repair.

It is possible to work high speed by adopting Logic Valve

It is possible to operate easily and various driving handling by using P.L.C ( Programable Logic Controller ).

It is easy to repair and catch a caue when happening problems.

Speciflcarion	CAPACITY (TON)	STROKE (mm)	DAYLIGHT (mm)	BOLSTAR SIZE (mm)	DESCENDING SPEED (mm/sec)	PRESSING SPEED (mm/sec)	ASCENDING SPEED (mm/sec)
KDP- 100	100	500	700	1000X800	250	15-28	250
KDP- 150A	150	550	800	1200X1000	250	16-27	250
KDP- 150B	150	700	1000	1500X1200	250	17-27	250
KDP- 200A	200	700	1000	1500X1200	250	17-20	250
KDP- 200B	200	700	1100	2000X1200	250	16-20	250
KDP- 250B	250	700	1200	2000X1200	280	13-23	280
KDP- 300B	300	800	1300	2000X1500	290	14-20	290
KDP- 400B	400	900	1400	2300X1500	250	10-20	200
KDP- 500B	500	1000	1500	2500X1500	250	10-17	215
KDP- 600	600	1000	1500	2500X1500	250	11-15	215
KDP- 800	800	1100	1600	2800X1500	200	10-15	200
KDP- 1000	1000	1200	1800	3000X1800	200	10-17	200

Speciflcarion	다이쿠숀 DIECUSHION			모 타 MOTORS
Speciflcarion	CAPACITY (TON)	STROKE (mm)	ASCEND (mm/SEC)	모 타 MOTORS
KDP- 100	35	220	85	19 5.5
KDP- 150A	50	300	60	30 2.2
KDP- 150B	50	300	60	30 2.2
KDP- 200A	70	300	55	37 5.5 2.2
KDP- 200B	70	300	55	37 5.5 2.2
KDP- 250B	85	300	70	37 7.5 2.2
KDP- 300B	100	350	70	45 7.5 3.7
KDP- 400B	140	400	60	45 7.5 3.7
KDP- 500B	170	450	60	55 11 3.7
KDP- 600	200	450	60	75 11 3.7
KDP- 800	270	500	60	15X2 15 5.5
KDP- 1000	350	550	60	55X2 15 5.5
