Main Function & Operation Type Washing fluid is being separated by the special inside-structure tank automatically.
Potential Customers Restaurant
Purpose To separate the food oil from washing fluid
Feature 1. World wide Patent Technology with the particular structure 2. Easy to install the built in tank into the washing basin 3. Separate the floating particles through the basket filtering net 4. Separate Wasted oil in the separator tank and drop & collect to the plastic bottle. 5. Filtered fluid is to auto influx to the outlet pipe. |
 |
Specification
ㆍApplied field : Restaurant
ㆍHow to operate : Based on the Gravity and Density of wasted washing fluid
| Capacity | 300ℓ/h | Weight | 60kg |
|---|---|---|---|
| Separator Tank Capacity | 40ℓ | Dimension | 500*300*600mm (w*L*H) |
| Electricity | 220V/60/50Hz single phase | Fluid Temperature | below 80℃ |
| Material | SUS |
Attention to Install
1. Install the product with Separator tank horizontally on the level.
2. Check the Inlet and outlet’s Function under the bottom of the product
3. Understand the patented structure of separator tank, Wasted Water level control lever for wasted water and Oil drain control lever for oil outlet
4. Prepare for the plastic bottle to collect the wasted oil
Attention to Operate
1. Remove the small particles on the basket filter screen often.
2. Clean the bottom of Separator tank when there are a lot of sludge on the bottom. Before cleaning, Open the drain valve under the tank and clean with air-gun efficiently.
