Metal to metal ball valve

Metal to metal ball valve

Model Name

Series

Products

View AllView All Series

Data

Manufacturer information

Samsung Precision

3 way valve and Jacket ball valve manufacturer

Inquiry

How to order

Problem with product info?

Update request

Manufacturer

Samsung Precision

Brand

SKU

28927

Product Name

Metal to metal ball valve

Model Name

Size

Weight

Product Details

Metal to metal ball valve

1. Manufacturing scope

Size : Full bore DN15 (1/2") ~ DN500 (20")
Class 150 : DN15 (1/2") ~ DN500 (20")
Class 300 : DN15 (1/2") ~ DN400 (16")
Class 600 : DN15 (1/2") ~ DN300 (12")
Pressure Rating : Class 150 ~ 600, JIS 10K ~ 30K
Working Temperature : '-40°C ~ +650°C

2. Standard Features

Face to face : ASME B16.10 , JIS B2002
End flange : ASME B16.5 , JIS B2238
Shell wall thickness : ASME B16.34 & BS5351
Fire safe design (API 607 , API 6FA & BS6755)
Anti-static device
Locking device
Blow-out proof stem
Design : ASME B16.34 , API 6D or BS5351

Samsung Precision

3 way valve and Jacket ball valve manufacturer

We, "SAMSUNG PRECISION IND. CO., LTD." are specialized in ball valve manufacturing since our foundation year in 1982, with zero - defect, high quality and competitive pricing. We produce various types of manual ball valves and special valves with state of the art testing equipment and international approval ISO 9001 & API Q1 quality systems. SAMSUNG, as a specialized valve manufacturer will make the highest quality products and guarantee complete satisfaction for our domestic and overseas customers.
