SIMACO
SIMACO
Description
| NAME | TYPE | P2 (KW) 50HZ / 60HZ |
DUAL-FREQUENCY (50/60HZ) |
Q MAX 50HZ | H MAX 50HZ | DN |
|---|---|---|---|---|---|---|
| VP 760 | 3 ph | 1.00/1.30 | R.F.T. | 66 | 52 | 3/4G |
CHARACTERISTICS
- Continuous duty S1.
- 2 pole motor.
- Insulation class F.
- Protection IP42 (IP 54 on demand).
- IE3 efficiency class for 3-phase motors >0,75 kW.
- Working tolerance: +/- 10%.
- Liquid temperature (with anti-freeze additive): -20 °C / +150 °C.
- Limit ambient temperature : -10 °C/+40 °C.
- For clear waters/oils and non-aggressive dilutions, without abrasive substances.
- Sister electric pump: VP640
ON REQUEST
- Special voltages.
- 60Hz version.
- Dual-frequency.
- Version for oil 200°C.
- Metal fan-cover.
- UL/CSA.
MATERIALS
- Casing dezincification-resistant CuZn
- Impeller dezincification-resistant CuZn
- Shaft AISI431
WEIGHT
10.45÷10.95 Kg
IN ACCORDANCE WITH
- EN 60034-1
- EN 60034-30
- EN 60335-1
- EN 60335-2-41
DIMENSIONS
HYDRAULIC PERFORMANCE
