TNE Timer
Model Name
-
Data
-
Manufacturer information
provider logo
TAEHA VALVE

Dust collector manufacturer, Air bank, Pulse valve, Gauge, Timer and more

Problem with product info?
Update request
Manufacturer
TAEHA VALVE
Brand
-
SKU
60614
Product Name
TNE Timer
Model Name
-
Size
-
Weight
-
Product Details

1. Aluminum Die-Casted Box

   As the PCB of TNE timer is located in the aluminum

   die-casted box, if facilitates the water-proofing and

   dust-proofing.



2. Economical design contains the essential functions

   only for the dust collector.



3. Exterior design

   It has exterior displays like LED lamp and main power

   switch.


Specification

TNE Timer

           Output Signal

                                  Electrical

           Feature

                                  Board only

           Control Type

                                  Analog

           Enclosure

                                  Aluminum Die-Casting NEMA 4

           Max. Output

                                  10p, 20p

           Pulse Time

                                  Volume register

           Dwell Time

                                  Volume register

           Power Supply

                                  AC85 ~ 240V / 50 ~ 60Hz

           Fuse

                                  2A

           Pressure

                                  -

           Operating

             Temperature

                                  320 ~ +60℃

                                  (If not freezing condition)

           Terminal Type

                                  1.25 4Y


More products
TAEHA VALVE
Dust collector manufacturer, Air bank, Pulse valve, Gauge, Timer and more
TAEHA has been a successful designer and manufacturer of dustcollector components for more than 30 years. The company's experience and dedication to their industry hashelped them to grow every year, the company shipped over 250,000 pulse valves to the world-wide market through distributors in more than 46 countries, making TAE HA on of the world's largest manufacturers of pulse valves and controls for dust collectors. With a goal to become the world's leading manufacturer, the TAEHA product range is under constant review to ensure the customer is getting the best value for money. New products and design changes are thoroughly tested in the local market before world release and as a valued TAE HA customer, you can be assured of quality, value and innovation. Factory testing of all new valve systems and products are carried out in the TAEHA performance test laboratory using the most advanced test facilities of any pulse valve manufacturer in the world. The laboratory is able to test all products for flow consumption and flow performance (Cv) to international standards, using constant flow / pressure hydraulic testing systems, and precision measuring instrumentation.
