TMF(Tubular Maintenance Free) Series Battery
Model Name
TMF1250
Series
TMF(Tubular Maintenance Free) Series Battery
Data
CATALOG-UKB-TMF(Tubular Maintenance Free) Series Battery
Manufacturer information
provider logo
UKB

Industrial batteries for UPS & Telecommunications, Solar Power System, traction batteries

Problem with product info?
Update request
Manufacturer
UKB
Brand
-
SKU
126349
Product Name
TMF(Tubular Maintenance Free) Series Battery
Model Name
TMF1250, TMF1270, TMF12100, TMF12120, TMF12150, TMF12200
Size
-
Weight
-
Product Details

TMF(Tubular Maintenance Free) Series Battery


TMF battery is specially designed for solar power system with tubular plate which required more material for thick plate. TMF was made according to tubular technology, it offers 2000 cycle at D.O.D. (Depth of Discharge) 50% conditionTMF battery use special Lead-Alloy for minimal fluid loss meaning that there is no need to replenish distilled water through the life of the battery.Calcium-Silver alloy grids provide prompt turnover even after long periods of standing.The use of Calcium-Silver alloy grids and Tubular thin Plate (Ø6.6mm) means that TMF batteries have 20% improved charging ability compared to other batteries, even during intense heat or cold.Special alloy grids prevent corrosion and extend the life of the battery..



APPLICATION

- SOLAR WAVE (P.V) POWERED SYSTEM
- IPS & UPS SYSTEM



FEATURES

- Tubular Positive Monoblock
- Deep Cycle Battery
- Over-Charge Resitance
- MF (Maintenance free) Type
- Have Hydrometer for Checking
- Prevent Internal Short Circuit



PRODUCTS RANGES

- 12V: 50AH ~ 250AH / 20Hr
- Electrolyte : Acid(MF TYPE)
- 1,250 CYCLES AT D.O.D 80% DISCHARGE CONDITION





More products
Industrial batteries for UPS & Telecommunications, Solar Power System, traction batteries
Since established in 1995, UKB has been involved in manufacturing and exporting a wide range of industrial batteries for UPS & Telecommunications, Solar Power Systems, and traction batteries for golf cars, forklifts, sweepers & electric vehicles to approximately 40 countries around the world.   With official JQA & JIS certifications, UKB is the only one battery maker which has successfully supplied to well-known Japanese electric power companies such as Tokyo, Kyushu and Kansai Electric Power Company among Korean & Chinese battery makers. UKB's core product, tubular-type deep cycle batteries are currently exported to 50 countries including Japan after the completion of its development in 2006.   In particular, the tubular type batteries which have been applied to traction batteries for the first time in Asia have superior performance in terms of its excellent power and longevity for cost reduction. These advantages brought highly favorable reactions in Japanese & Korean traction battery markets and this is expected to contribute substantially to the company's growth in the near future.   In addition, UKB still maintains a battery plant project team. The team has transferred cutting-edge advanced technologies and know-how for manufacturing batteries & its plants to Iran, Pakistan, India, China, Vietnam & Nigeria, Egypt, and CIS countries and has gained a high reputation as a forerunner of the battery technology. We assure you that our skilled and experienced engineers are always ready to help you with the production of the state-of-the-art batteries wherever you are in the world.   As a highly specialized battery company, we will be fully committed to satisfying our customers by focusing on the production of high quality & innovative batteries. For the details of our UKB products, please feel free to contact us at ukb@ukbkorea.com or visit us at www.ukbkorea.com.
