product Image
Auto PVC Sol Dispenser M/C
Model Name
UDD-200A
Series
Component Production Line
Data
UDD-200A
Manufacturer information
provider logo
Union Tech

Automotive filter equipment manufacturer, Union Tech, Seaming, Tapping, Clipping

Problem with product info?
Update request
Manufacturer
Union Tech
Brand
-
SKU
33723
Product Name
Auto PVC Sol Dispenser M/C
Model Name
UDD-200A
Size
-
Weight
-
Product Details

Union Tech Auto PVC Sol Dispenser M/C UDD-200A

TECHNICAL DESCRIPTION

ㆍCYLINDER NOZZLE TYPE

ㆍAVAILABLE CAP HEIGHT : 5~15mm

ㆍAVAILABLE CAP OUT-DIA : 60~95mm

ㆍPRODUCTION CAPACITY : 30~40 pcs/ min

ㆍFEEDING SYSTEM : ROLL FEEDING SYSTEM

ㆍMACHINE DIAMENTION : W1200 x L1600 x H1800

ㆍMACHINE WEIGHT : 1000 kg

ㆍDISPENSER CONTROL STYLE : TIMER SYSTEM

ㆍDRIVING MOTOR : 0.75 kw

ㆍAIR SUPPLY PRESSURE : 6kgf/Union Tech Auto PVC Sol Dispenser M/C UDD-200A 1

ㆍELECTRICITY : 380/ 220V x 50/ 60 Hz

ㆍEASY TO CHANGE THE DIFFERENT MODEL BY USING OF ADJUSTING HANDLE

ㆍINCLUDED 2 LINE CONVEYOR SYSTEM FOR UPPER & BOTTOM END CAP

OPTIONAL PAPRT

ㆍAUTO LOADING PARTS FEEDING DEVICE LOADING PUMP(DRUM TO TANK LOADING) or LOADING & MIXING DEVICE or RAM PUMP PVC SOL MATERIAL

Union Tech
Automotive filter equipment manufacturer, Union Tech, Seaming, Tapping, Clipping
Union Tech machines are designed with the highest quality for continued performance in the most demanding of environments. Companies worldwide have embraced the concepts and technologies pioneered by Union Tech, and our machines are now in operation in more than 25 countries around the globe. We appreciate your kind attention to Union Tech which has done systematic study and has made incessant endeavor to produce the safest and the most convenient equipment for the customers, based ton technology and know-how accumulated over the twenty six years since work in filter industrial. With confidence we can assure you that Union Tech will be a dependable partner of promising future and development of your company through strict quality management, fast and exact after service, and far advanced technology for customer’s convenience and satisfaction, and the craftsmanship for the utmost results.
