제품 상세스펙
규격 | FLANGE SIZE | LAPJOINT SIZE | L | A | 공차 |
---|---|---|---|---|---|
13SU | 15A-10kg/cm² | 15A | 66 | 44 | ±3 |
20SU | 20A-10kg/cm² | 20A | 68 | 43 | ±3 |
25SU | 25A-10kg/cm² | 25A | 95 | 70 | ±3 |
30SU | 32A-10kg/cm² | 32A | 110 | 73 | ±3 |
40SU | 40A-10kg/cm² | 40A | 114 | 73 | ±3 |
50SU | 50A-10kg/cm² | 50A | 124 | 79 | ±3 |
60SU | 65A-10kg/cm² | 65A | 152 | 104 | ±5 |
75SU | 65A-10kg/cm² | 65A | 139 | 67 | ±5 |
80SU | 80A-10kg/cm² | 80A | 146 | 68 | ±5 |
100SU | 100A-10kg/cm² | 100A | 148 | 68 | ±5 |
