신성전자(주)
Relay Group
모델명
시리즈
Public Address System
구매 안내
아래는 참고용 정보이므로 세부 조건은 반드시 제조사/판매자에게 문의 바랍니다.
결제 방법
제조사/판매자에게 문의 바랍니다.
납기 정보
제조사/판매자에게 문의 바랍니다.
배송 정보
제조사/판매자에게 문의 바랍니다.
원산지
제조사/판매자에게 문의 바랍니다.
제품 상세 설명
Feature of Product
•It is composed by two groups of the circuit exclusive for apartment broadcasting facility
•It provides the signal receiving unit interlocking function for each floor(B1-28F, parking lot) and switch (parking lot, whole unit) function.
•It has two REMOTES(RM ALL, SP ALL) and enables the control of overall operation and parking lot without regard to the priority-based sequence.
•It displays the floor where the fire started and the floor right above and below such a floor in accordance with the LAW ON FIRE PREVENTION AND FIGHTING if the‘ fire detection unit interlocking system’is activated.
Size and Function
•Fire Control/indicator : 30CH, 2 Group
•Remote Control : 2CH
•AMP Input : 2CH
•Speaker Output : 30CH, 2 Group
•Power Source : DC 24V
•Weight : 4.8kg
•Dimensions : 483(W) x 44.5(H) x 320(D)mm
Feature of Product
•This device is composed by the circuit exclusive for apartment broadcasting facility.
•It provides the signal receiving unit interlocking function for each floor(B1-28F,parking lot) and switch (parking lot, whole unit) function.
•It has two REMOTES(RM ALL, SP ALL) and enables the control of overall operation and parking lot without regard to the priority-based sequence.
•It displays the floor where the fire started and the floor right above and below such a floor in accordance with the LAW ON FIRE PREVENTION AND FIGHTING if the‘ fire detection unit interlocking system’is activated.
Size and Function
•Fire Control/indicator : 30CH
•Remote Control : 2CH
•AMP Input : 1CH
•Speaker Output : 30CH
•Power Source : DC 24V
•Weight : 3.6kg
•Dimensions : 483(W) x 44.5(H) x 320(D)mm
Feature of Product
•With the ordinary and emergency speaker output, its broadcasting circuit can be based on two-wire and three-wire system.
•Ordinary broadcasting : 2-wire system(HOT,COM)
•Emergency broadcasting : 3-wire system(HOT,COM,EM)-ATT
•The broadcasting area can be checked with lamp that indicates the operation circuit(LED display based on 16 circuits).
Size and Function
•AMP Input : 16 Ch
•Speaker line : 16 Ch
•Control line : 17 Ch
•Power Source : DC 24V
•Weight : 2.1kg
•Dimensions : 270(W) x 44.5(H) x 320(D)mm
Feature of Product
•With the ordinary and emergency speaker output, its broadcasting circuit can be based on two-wire and three-wire system.
•Ordinary broadcasting : 2-wire system(HOT, COM)
•Emergency broadcasting : 3-wire system(HOT, COM, EM)-ATT
•The broadcasting area can be checked with lamp that indicates the operation circuit(LED displaybased on 16 circuits).
Size and Function
•AMP Input : 16 Ch
•Speaker line : 16 Ch
•Control line : 17 Ch
•Power Source : DC 24V
•Weight : 3.5kg
•Dimensions : 483(W) x 44.5(H) x 320(D)mm
