SPECIFICATIONS
AUTO FEEDING TANDEM SLITTER |
|
MAX. SHEET DIMENSION |
1200 X 1200 |
MIN. SHEET DIMENSION |
700 X 700 |
MAX. SHEET THICKNESS |
0.4 MM |
HORSE POWER REQUIRED |
3 HP, 1 HP X 2 = 5 HP |
FLOOR SPACE |
1600 X 1300 X 1500 |
NET WEIGHT (APPROX.) |
6000 KG |
VACUUM PUMP |
3 HP |
CAPACITY PER MIN. |
25~38 SHEETS/MIN. |
FEATURES
* CENTRAL LUBRICANT OIL SYSTEM : AUTO OIL PUMP MAKES MACHINE SMOOTH AND LAST MACHINE LIFE.
* HIGH RIGID FRAME : RATIONALLY DESIGNED FRAME KEEPS SUFFICIENT STRENGTH AND MAINTAINS ACCURATE PRECISION FOR DYNAMIC LOAD.
* INVERTOR IS AVAILABLE FOR VARIABLE RUNNING SPEED
* PLC CONTROL
