SPECIFICATIONS
DOUBLE DIE PRESS |
|
RANGE OF CAN DIAMETER |
200~401 D |
MAX. LENGTH OF STRIP |
1060 MM |
MIN. LENGTH OF STRIP |
510 MM |
MAX. WIDTH OF STRIP |
220 MM |
MIN. WIDTH OF STRIP |
130 MM |
MAX. CUTS PER STRIP |
13 PCS |
MIN. CUTS PER STRIP |
5 PCS |
STROKE PER MIN. |
100~200 SPM |
HORSE POWER REQUIRED |
7 1/2, 1/4, 1/4 HP |
FLOOR SPACE |
3450 X 2460 X 1800 MM |
NET WEIGHT |
5500 KG |
