Specifications
규격 | NW16, NW25, NW40, NW50 |
재질 | Aluminum |
사용가능 펌프 | NW16 : W2V05, NW25 : W2V10~40 |
NW40 : W2V60~180 / NW50 : NW50-Inlet/Outlet |
Outer Dimension (unit : mm)
품목명 | 규격명 | 품목코드 | D | d | H | T |
Clamp | NW16 | ACCCMA001610 | 42 | 20 | 61 | 17 |
Clamp | NW25 | ACCCMA002510 | 52 | 30 | 73 | 17 |
Clamp | NW40 | ACCCMA004010 | 70 | 44 | 90 | 17 |
Clamp | NW50 | ACCCMA005010 | 94 | 62 | 123 | 17 |
