Hydraulic Breaker Manufacturer
Spectification
ITEMS / MODEL | D&A 6V | D&A 8V | D&A 17V | |
Operation Weight | kg | 55 | 120 | 187 |
lbs | 121 | 265 | 412 | |
Required Oil Flow | lpm | 18~25 | 15~30 | 23~70 |
gpm | 4.76~6.60 | 3.96~9.25 | 6.08~18.49 | |
Operating Pressure | kg/㎠ | 60~130 | 90~120 | 90~120 |
psi | 853~1,849 | 1,280~1,707 | 1,280~1,707 | |
Number of Blow (Long stroke) | bpm | 800~1,200 | 550~1,000 | 600~1,500 |
Hammer Tool | mm | 40 | 45 | 57 |
inch | 1.57 | 1.77 | 2.24 | |
Relief Valve Setting Pressure | kg/㎠ | 175 | 175 | 175 |
psi | 2,489 | 2,489 | 2,489 | |
Suitable Carrier | ton | 0.5~2.0 | 0.8~2.5 | 1.5~4.0 |
lbs | 1,102~4,409 | 1,764~5,512 | 3,307~8,818 | |
Accumlator Pressure | kg/㎠ | |||
psi |
Remark
Above specifications are subject to change without notice
