Welding M/C manufacturer, DC arc welder, TIG, Argon, CO2, MAG welder, Plasma cutter, Mixed type gas welder and more
Special Feature
* Possible welding of all kinds of meatais using one machine
* Design for convenient use
* High-quality welding using pulse function
* Built-in remote control function
* Built-in self-inspection function of the disorder of the machine
* Possible single-phase or triple-phase input
* 220V/380V/440V combined use
Specification |
|||
Process |
|
TIG |
STICK |
Output Current |
A |
3 Phase - 350 |
230 |
1 Phase - 220 |
|||
Input Voltage |
V |
220V / 380V / 440V ± 10% |
|
Rated Frequency |
Hz |
50/60 |
|
Rated Input |
KVA / KW |
12.2 |
|
Rated load Voltage |
V |
24 |
|
No load Voltage |
V |
67 |
|
Duty Cycle |
% |
60 |
|
Output Current range |
A |
10 ~ 350 |
15 ~ 230 |
Gas After flow |
sec |
0.1 ~ 10 |
|
Down Slope |
sec |
0.1 ~ 10 |
|
Arc Spot |
sec |
0.1 ~ 10 |
|
Pluse Frequency |
Hz |
LOW : 0.5~15, HI : 15~500 |
|
Pluse Width |
% |
15 ~ 85 |
|
Crater control |
|
Off, On, Repeat |
|
Dimension (WxDxH) |
mm |
380 x 623 x 580(380 x 693 x 615) |
|
Weight |
kg |
55 |
※ Product specifications can be changed unexpectedly for product performance improvement.
※ Remote control is separate way option.
