AC/DC Welding Machine (DB Series)
Model Name
DB-500AN
Series
AC/DC Welding
Data
-
Manufacturer information
provider logo
JOYOUNG WELDING

Welding M/C manufacturer, DC arc welder, TIG, Argon, CO2, MAG welder, Plasma cutter, Mixed type gas welder and more

Problem with product info?
Update request
Manufacturer
JOYOUNG WELDING
Brand
-
SKU
130053
Product Name
AC/DC Welding Machine (DB Series)
Model Name
DB-500AN
Size
-
Weight
-
Product Details

Special Feature

* Possible welding of all kinds of meatais using one machine
* Design for convenient use
* High-quality welding using pulse function
* Built-in remote control function
* Built-in self-inspection function of the disorder of the machine
* Possible single-phase or triple-phase input
* 220V/380V/440V combined use





Specification

Process



TIG

STICK

Output Current

A

3 Phase - 500

290

1 Phase - 320

Input Voltage

V

220V / 380V / 440V ± 10%

Rated Frequency

Hz

50/60

Rated Input

KVA / KW

19.1

Rated load Voltage

V

30

No load Voltage

V

67

Duty Cycle

%

50

Output Current range

A

10~ 500

15 ~ 290

Gas After flow

sec

0.1 ~ 10

Down Slope

sec

0.1 ~ 10

Arc Spot

sec

0.1 ~ 10

Pluse Frequency

Hz

LOW : 0.5~15, HI : 15~500

Pluse Width

%

15 ~ 85

Crater control



 Off, On, Repeat

Dimension (WxDxH)

mm

380 x 623 x 580(380 x 693 x 615)

Weight

kg

56



※ Product specifications can be changed unexpectedly for product performance improvement.

※ Remote control is separate way option.

JOYOUNG WELDING
Welding M/C manufacturer, DC arc welder, TIG, Argon, CO2, MAG welder, Plasma cutter, Mixed type gas welder and more
Selection of welder determines the productivity and quality. Our company is trying to return support of customer as welding machine specialty manufacture company. Major products include the welding machine, plasma cutting machine, torch accessory.   Our company promises to contribute in productivity and quality of customer by the best service, the superlative quality, a best technology. Product that is new technology development so that can be enterprise which develops with customer hereafter continuously announced be going to.
