product Image
Electric Press
Model Name
e-P50
Data
-
Manufacturer information
provider logo
NUMALLIANCE

Providers of Turnkey Productivity Solutions for Cold Forming Metal Wire, Tube, and Flat-stock

Problem with product info?
Update request
Manufacturer
NUMALLIANCE
Brand
-
SKU
142890
Product Name
Electric Press
Model Name
e-P50, e-P100
Size
-
Weight
-
Product Details

Technical presentation of the e-P

Key features
  • Press technologies: electrical axis with high efficiency, speed, accuracy and dynamic movement
  • Compact and easy integration into automatic cell
  • Multilingual dialog and programming interface on a 12’’ touch screen
  • Multi-Function control panel
  • Safety brakes
  • Full tonnage throughout the stroke
  • Real time effort control
  • Integrated operations tooling
  • Remote control assistance
  • User-friendly programming software – skynet
  • Predictive maintenance – real time efforts measurements
Benefits of electrics
  • Clean and quiet operation
  • Energy savings
  • High accuracy and repeatability
  • Variable kinematics
  • Controlled forming speed and position
  • Low maintenance
  • Full control on all speed range
  e-P50 e-P100
Press Types H-frame H-frame
Maximum force 50T 100T
Moving part Upper platen Upper platen
Tables/Platens dimensions 1000 x 800 mm 1000 x 800 mm
Features of the tables / platens T-slotes T-slotes
Stroke 500 mm 500 mm
Daylight 800 mm 800 mm
Fast Approach speed 200 mm/s 200 mm/s
Automation / Display Skynet / 12" Skynet / 12"
Pressure sensor Force sensor Force sensor
Operator safety (option) Side panels + SICK light curtains Front Side panels + SICK light curtains Front
Safety SITEMA SITEMA
Dimensions 1710x1280x3500mm 1710x1280x3500mm
Weight 8T 9T

Example of parts made with the e-P
