Small & Compact Range
TRH 10TR~TRH 120TR
Top Rock, TRH Silenced Series
Combines high operation efficiency and nitrogen gas energy to achive powerful breaking force, even in the toughest conditions.
They are suitable for demolition and recyling work, canalisation work, surface construction, excavation and civil engineering work and roadworks, for work in quarries, renovation and cutting, as well as garden and landscaping works.
Specification
Description | Unit | TRH10TR | TRH20TR | TRH30TR | TRH50TR | TRH60TR | TRH90TR | TRH120TR | |
---|---|---|---|---|---|---|---|---|---|
Operating Weight (including tool) |
With Mount Cap |
kg | 150 | 210 | 270 | 360 | 460 | 600 | 950 |
lbs | 331 | 463 | 595 | 794 | 1,014 | 1,323 | 2,094 | ||
Overall Height (including tool) |
With Mount Cap |
mm | 1,135 | 1,350 | 1,420 | 1,586 | 1,729 | 1,946 | 2,338 |
inch | 44.7 | 53.1 | 55.9 | 62.4 | 68.1 | 76.6 | 92.0 | ||
Without Mount Cap |
mm | 998 | 1,110 | 1,220 | 1,386 | 1,479 | 1,726 | 2,053 | |
inch | 39.3 | 43.7 | 48.0 | 54.6 | 58.2 | 68.0 | 80.8 | ||
Operating Pressure | bar | 80 ~ 110 | 80 ~ 110 | 90 ~ 120 | 95 ~ 130 | 100 ~ 130 | 130 ~ 150 | 150 ~ 170 | |
psi | 1,160 ~ 1,595 | 1,160 ~ 1,595 | 1,305 ~ 1,740 | 1,378 ~ 1,885 | 1,450 ~ 1,885 | 1,885 ~ 2,176 | 2,176 ~ 2,465 | ||
Setting Pressure | bar | 150 | 150 | 150 | 170 | 170 | 195 | 210 | |
psi | 2,175 | 2,175 | 2,175 | 2,465 | 2,465 | 2,828 | 3,045 | ||
Required oil flow | ℓ/min | 15 ~ 30 | 20 ~ 30 | 25 ~ 50 | 30 ~ 50 | 40~80 | 45~90 | 80 ~ 110 | |
gpm | 4 ~ 8 | 5.3 ~ 8.0 | 6.6 ~ 13.2 | 8.0 ~ 13.2 | 10.5 ~ 21.1 | 11.9 ~ 23.8 | 21.1 ~ 29.1 | ||
Backhead Pressure | bar | 16 | 16 | 16 | 16 | 16 | 16 | 16 | |
psi | 232 | 232 | 232 | 232 | 232 | 232 | 232 | ||
Accumulator Pressure | bar | - | - | - | - | - | - | - | |
psi | - | - | - | - | - | - | - | ||
Impact Rate | bpm | 800 ~ 1,400 | 600 ~ 1,200 | 550 ~ 1,000 | 450 ~ 900 | 450 ~ 900 | 400 ~ 800 | 450 ~ 700 | |
Tool Shank Diameter | mm | 40 | 45 | 53 | 68 | 75 | 85 | 100 | |
inch | 1.57 | 1.77 | 2.08 | 2.67 | 2.95 | 3.34 | 3.93 | ||
Impact Energy | Joule | 399 | 416 | 492 | 849 | 1,210 | 1,764 | 2,443 | |
ft.lb | 294 | 307 | 363 | 626 | 892 | 1,301 | 1,802 | ||
Suitable Machine | ton | 0.8 ~ 2.5 | 1.2 ~ 3.0 | 2.0 ~ 3.5 | 4 ~ 6 | 5 ~ 9 | 7 ~11 | 11 ~ 16 | |
lbs | 1,764~5,511 | 2,645~6,614 | 4,409~7,716 | 8,818~13,228 | 11,023~19,841 | 15,432~24,251 | 24,251~35,274 |
* The above specifications are subject to change without prior notice for the quality enhancement.
Breaker Tool (Right Tool Selection)
The right selection of working tool is start of demolition and decide on breaking performance.
The tool should be selected by breaking material and job condition as well.
