Top Rock Open Housing
Model Name
TRH190V
Series
Hydraulic Breaker
Data
-
Manufacturer information
provider logo
Shinil SNC

Construction attachment, Vibro hammer, Ripper and Breaker manufacturer

Problem with product info?
Update request
Manufacturer
Shinil SNC
Brand
-
SKU
131279
Product Name
Top Rock Open Housing
Model Name
TRH190V, TRH220V, TRH350V, TRH450V, TRH550V, TRH650V, TRH750V
Size
-
Weight
-
Product Details

Medium & Large Range

-Available from 14tons to 75 tons heavy class excavators

-High impact power and impact rate

-Patented sealing and piston guidance system

-Low Operation costs

-High Efficient design & Appearance

-Tool Bushing engineered for quick&easy replacement

Application ; Primary and secondary breaking in quarries, Foundation works, Road construction, Demolition works, highly reinforced concrete, mining, Trenching, Bench leveling, General construction works.





Specification

Description Unit TRH190V TRH220V TRH350V TRH450V TRH550V TRH650V TRH750V
Operating Weight
(including tool)
With
Mount Cap
kg 1,580 1,880 2,480 3,180 4,250 5,470 6,750
lbs 3,483 4,145 5,467 7,011 9,370 12,059 14,881
Overall Height
(including tool)
With
Mount Cap
mm 2,480 2,773 3,046 3,281/td> 3,758 4,130 4,443
inch 97.6 109.2 119.9 129.2 148.0 162.6 174.9
Without
Mount Cap
mm 2,120 2,413 2,686 2,839 3,316 3,520 3,753
inch 83.5 95.0 105.7 111.8 130.6 138.6 147.8
Operating Pressure bar 150 ~ 170 160 ~ 180 160 ~ 180 170 ~ 190 170 ~ 190 200 ~ 230 210 ~ 240
psi 2,176 ~ 2,466 2,320 ~ 2,611 2,320 ~ 2,611 2,466 ~ 2,756 2,466 ~ 2,756 2,901 ~ 3,336 3,046 ~ 3,481
Setting Pressure bar 210 210 230 230 240 240 270
psi 3,046 3,046 3,336 3,336 3,481 3,771 3,916
Required oil flow ℓ/min 90 ~ 120 130 ~ 150 160 ~ 190 190 ~ 210 190 ~ 210 200 ~ 230 210 ~250
gpm 23.78 ~ 31.70 34.34 ~ 39.63 42.26 ~ 50.19 50.19 ~ 55.47 50.19 ~ 55.47 52.83 ~ 60.76 55.47 ~ 66.04
Backhead Pressure bar 6 6 6 8 11 17 17
psi 87 87 87 116 160 247 247
Accumulator Pressure bar 60 60 60 60 60 60 60
psi 870 870 870 870 870 870 870
Impact Rate bpm 400 ~ 900 400 ~ 800 350 ~ 750 300 ~ 500 240 ~ 310 150 ~ 280 150~250
Tool Shank Diameter mm 120 135 150 160 180 190 210
inch 4.7 5.3 5.9 6.3 7.1 7.5 8.3
Impact Energy Joule 4,234 5,717 9,150 9,980 13,125 14,800 17,500
ft.lb 3,123 4,217 6,749 7,361 9,681 10,916 12,907
Suitable Machine ton 13 ~ 18 18 ~ 26 28 ~ 35 33 ~45 45 ~ 55 48 ~ 65 55 ~ 75
lbs 28,660~39,683 39,683~57,320 61,729~77,162 72,753~99,208 99,208~121,254 105,822~143,300 121,254~165,346

* The above specifications are subject to change without prior notice for the quality enhancement.





Breaker Tool (Right Tool Selection)

The right selection of working tool is start of demolition and decide on breaking performance.

The tool should be selected by breaking material and job condition as well.
