PRT-SH
If the cable line requires thin threads and high manufacturing speed, such as automobile cables, then you need high speed torque.
This is required because you want to prevent faults caused by delayed printing. In addition, you need to pump ink very fast for high speed printing, and you can use the ink pump mounted for this purpose.
PRT-DH
Cable Printer is designed to perform gravure printing of brand name, product name, or specs on the PE, PVC, LDPE, and TEFLON cables.
Cable Printers are available for two speed settings-high speed and low speed. High speed rotating printing material is torque-controlled by the servo motor. High speed, precision printing can be accomplished. Line Speed 1,000mpm printing can be accomplished.
PRT-SL 10
For cable manufacturing speed slower than 300mpm, a simple printer is more suitable.
That is why the PRT-SL10 is frequently used in such manufacturing lines.
Easy to use. Easy to replace the scraper. No need for pavld. Just dip it little bit for printing.
PRT-SL 80
Despite the slow manufacturing speed, when you have a thick cable, you need to use the air pressure to lift up the printing guide roll or pressurize it from top to bottom.
The best model for this purpose is our PRT-SL80 model.
Product Specs
| MODEL | PRT-SL10 | PRT-SL35 | PRT-DL35 | PRT-SL80 | PRT-SH 500/1000 | PRT-DH 500/1000 |
| TYPE | Low speed printing | High speed printing | ||||
| Applicable(mm) | ∅0.5 ~10 | ∅3~35∅ | ∅10~80 | ∅9mm below | ||
| Line speed Max(mm) | 400 | 100 | 500/1000 | |||
| Line center(mm) | 900~1100 | |||||
| Print head | 1EA | 2EA 1SET | 1EA | 1EA | 2EA 1SET | |
| Roll drive | Wire draw | SH 500 : Non Motor | DH 500 : Non Motor | |||
| SH 1000 : Servo Motor Drive | DH 1000 : Servo Motor Drive | |||||
| Roll size | ∅100 X 10mm | |||||
| Ink pump | Ink mix roll motor | Gear pump | ink mix roll motor | Air pump | ||
| The feeback of ink | Fixed | Auto adjustment according to speed | ||||
| Pneumatic | 3Kbf/ ㎠ beyond | |||||
| Size | 400 X 1500 X 600 | 700X1250X630 | 745X1430X570 | |||
| Power supply | 200VAC 50/60Hz | |||||
