Features
Hight Speed
High-performance 1GHz CPU is installed to improve data and screen switching speed, and Windows CE 6.0 Professional OS is adopted to execute NET-based external applications.
Large Memory
Large device memory is provided to save mass data.
Presence Sensor
To control the backlight, the sensor detects movement within 1m, ensuring longer life of the product.
More Colorful
High luminance/resolution LCD with an LED backlight and 24 bit colors to express clear and vivid colors of 16,777,216.
1 Respective Front USB Host/Device Channel
ㆍAn additional USB host channel is installed in the front panel.
ㆍA front USB host is used to connect to a USB memory, mouse, and keyboard.
ㆍA front USB device port is used to change the XP-Runtime without opening a control panel or download/upload the drawing file created using XP-Builder.
Sound Output Function (For all iXP models)
ㆍThe sound files (wav, mp3) registered using XP-Builder can be output to speakers connected to HMI.
ㆍAn alarm is generated via speakers to warn the operator.
ㆍUp to 512 sound files can be saved.
Function to use SD Cards
iXP supports additional SD memory cards along with previous USB memory to diversify backup means.
Presence Sensor (For all iXP models)
ㆍThe XP presence sensor detects movement within 1m to turn on the backlight.
ㆍWhen not in use, it turns OFF the screen to maintain a longer lifespan of the backlight.
Specifications
General Information
| Item | Description | Standard | |||
|---|---|---|---|---|---|
| Ambient temperature | 0℃∼+50℃ | ||||
| Storage temperature | -20℃∼+60℃ | ||||
| Ambient humidity | 10∼85%RH, without dew condensation | ||||
| Storage humidity | 10∼85%RH, without dew condensation | ||||
| Vibration resistance | Occasional vibration | Counts | |||
| Frequency | Acceleration | Amplitude | 10 times each direction (X, Y and Z) |
IEC 61131-2 | |
| 5≤ f < 9㎐ | - | 3.5mm | |||
| 9≤ f ≤ 150㎐ | 9.8m/s2 | - | |||
| Continuous vibration | |||||
| Frequency | Acceleration | Amplitude | |||
| 5≤ f < 9㎐ | - | 1.75mm | |||
| 9≤ f ≤ 150㎐ | 4.9m/s2 | - | |||
| Shock resistance | Maximum shock acceleration: 147m/s2 (15g) * Authorization time: 11ms * Pulse waveform: Half-sine wave (3 times each of X, Y and Z) * |
IEC 61131-2 | |||
| Vibration resistance | Square wave impulse noise | DC: ±1,200V AC: ±1,800V | LSIS Standards | ||
| Electrostatic discharge | ±4kV (Contact discharge) | IEC 61131-2, IEC 61000-4-2 |
|||
| Radiated electromagnetic field noise | 80 ~ 100MHz, 10V/m | IEC 61131-2, IEC 61000-4-3 |
|||
| Fast transient/Burst noise | Power Module: 2 kV, Communication Interface: 1kV | IEC 61131-2, IEC 61000-4-4 |
|||
| Operating ambience | Free from corrosive gas and excessive dust | ||||
| Altitude | 2,000m (6,562ft) or below | ||||
| Pollution degree | 2 or under | ||||
| Cooling method | Natural air-cooling | ||||
Dimensions
