DESCRIPTION | STANDARD | ORDER MAD | |
SUBSTRATE | OPP, CPP, PET AND THE OTHER PLASTIC FILMS | ||
WORKING WIDTH | MAX. 1100mm | ||
MACHINE SPEED | MAX. 250m/min | ||
SLITTING KNIFE | RING KNIFE OR RAZOR KNIFE | ||
MAIN DRIVING MOTOR | V.S MOTOR | D.C MOTOR | |
UNWINDER | TYPE | HYDRAULIC LIFTING ARM TYPE | |
REEL DIAMETER | MAX.ф600mm | MAX.ф800mm | |
EDGE CONTROL | HYDRAULIC ACTUATOR WITH L. F. C | ||
TENSION CONTROL | AUTOMATIC CONTROLLER WITH POWDER BRAKE | ||
REWINDER | REEL DIAMETER | MAX.ф400mm | MAX.ф500mm |
TOUCH ROLL | PNEUMATIC CONTROL SYSTEM | ||
TENSION CONTROL | TAPER TENSION WITH POWDER CLUTC |
