DESCRIPTION | STANDARD | ORDER MADE | |
SUBSTRATE | PAPER (21 ~ 50gr/m2) WITH AL - FOIL (6 ~ 8μ) | ||
WORKING WIDTH | MAX. 1100mm | ||
MACHINE SPEED | MAX. 300m/min | ||
SLITTING KNIFE | RING KNIFE CUTTING | ||
MAIN DRIVING MOTOR | V.S MOTOR | D.C MOTOR | |
UNWINDER | REEL DIAMETER | MAX.ф1100mm | |
EDGE CONTROL | HYDRAULIC ACTUATOR WITH E. P. C | ||
TENSION CONTROL | AIR BRAKE WITH REGULATOR | ||
REWINDER | TYPE | SURFACE & CENTER WIDING TYPE | |
TOUCH ROLL | PNEUMATIC CONTROL SYSTEM | ||
REEL DIAMETER | MAX.ф400mm | ||
TENSION CONTROL | V.S MOTOR | D.C MOTOR OR POWDER CLUTCH |
