DESCRIPTION | SPECIFICATION | ||
SUBSTRATE | OPP, CPP, PET AND THE OTHER PLASTIC FILMS, PAPER, AL - FOIL | ||
WORKING WIDTH | MAX. 1100mm | ||
WORKING WIDTH | MAX. 200m/min | ||
COATING METHOD | DIRECT GRAVURE ROLL COATING WITH SMOOTH BAR | ||
DRYER | NOZZLE TYPE | JET NOZZLE AND QUICK RETURN TYPE | |
HOOD OPEN TYPE | PNEUMATIC CYLINDER | ||
HEATING SOURCE | STEAM CONVECTOR, GAS BURNER, ELECTRIC HEATER, ETC | ||
WINDING SYSTEM | TURRET ARM TYPE, CENTER WINDING SYSTEM | ||
CORE CHUCKING | AIR EXPANSION SHAFT | ||
WEB GUIDE | 1st UNWINDER | AUTOMATIC CONTROL BY EPC(LPC) | |
2nd UNWINDER | AUTOMATIC CONTROL BY EPC(LPC) | ||
WINDING DIAMETER | UNWINDER(1st & 2nd) | ф600mm | |
REWINDER | ф800mm | ||
DRIVING SYSTEM | D.C MOTOR OR A.C VECTOR MOTO |
