DESCRIPTION | SPECIFICATION | ||
SUBSTRATE | AL - FOIL 50 ~ 200μ | ||
WORKING WIDTH | MAX.1350mm | ||
WORKING WIDTH | MAX.100m/min | ||
WORKING TENSION | 50 ~ 200Kg | ||
COATING SYSTEM | BOTH SIDE SINGLE COATING SYSTEM | ||
FOR SIDE | REVERSE ROLL COATING | ||
BACK SIDE | REVERSE KISS COATING | ||
FINALLY | TWO ROLL TURRET TYPE SMOOTH BAR COATING | ||
DRIVING SYSTEM | EACH ROLL SECTIONAL DRIVING WITH MOTOR | ||
DRYING OVEN | TYPE | AIR FLOATING NOZZLE TYPE | |
TEMPERATURE | MAX. 350ºC | ||
MATERIAL | STAINLESS STEEL | ||
HEATING SOURCE | L. P. G OR L. N. G | ||
UNWINDER & REWINDER | CORE | STEEL CORE | |
COIL DIA | MAX.ф1500mm | ||
DRIVING SYSTEM | D.C MOTOR OR A.C VECTOR MOTOR |
