DESCRIPTION | SPECIFICATION | ||
SUBSTRATE | AL - FOIL 50 ~ 200μ | ||
WORKING WIDTH | MAX.1350mm | ||
WORKING WIDTH | MAX.100m/min | ||
WORKING TENSION | 50 ~ 200Kg | ||
DEGREASING | ALKALI WATER | ||
HOT WATER | |||
PURE WATER | |||
FLAT SPRAY NOZZLES WITH SQUEEZING ROLLERS | |||
DRYING OVEN | TYPE | AIR FLOATING NOZZLE TYPE | |
TEMPERATURE | MAX. 120OC | ||
HEATING SOURCE | ELECTRIC HEATER OR STEAM HEATER | ||
UNWINDER & REWINDER | CORE | STEEL CORE | |
COIL DIA | MAX.ф1700mm | ||
DRIVING SYSTEM | D.C MOTOR OR A.C VECTOR MOTOR |
