DESCRIPTION | STANDARD | ||
SUBSTRATE | PAPER (21 ~ 150gr/m2) | ||
WORKING WIDTH | MAX. 1100mm | ||
MACHINE SPEED | MAX. 200m/min | ||
SLITTING KNIFE | SHER KNIFE CUTTING | ||
MAIN DRIVING MOTOR | V.S MOTOR | ||
UNWINDER | REEL DIAMETER | MAX.ф1000mm | |
EDGE CONTROL | HYDRAULIC ACTUATOR WITH E. P. C | ||
TENSION CONTROL | POWDER BRAKE WITH AUTO TENSION CONTROLLER | ||
REWINDER | TYPE | SURFACE & CENTER WIDING TYPE | |
PRESS CONTROL | HYDRAUUC CONTROL WITH PNEUMATIC CONTACTOR ROLL SYSTEM | ||
REEL DIAMETER | MAX.ф450mm | ||
TENSION CONTROL | POWDER CLUTC |
